TP-Link TL-SG1024S – 24-Port Gigabit Desktop/Rackmount Ethernet Switch

TP-LINK Technologies Co., Ltd

TL-SG1024S

TP-Link

TL-SG1024S

24-Port Gigabit Desktop/Rackmount Switch

What This Product Does

The TL-SG1024S Gigabit Ethernet Switch provides you with a high-performance, low-cost, easy-to-use, seamless and standard upgrade to improve old network to 1000Mbps network. All 24 ports support auto MDI/MDIX, no need to worry about the cable type, simply plug and play. Moreover, with the innovative energy-efficient technology, the TL-SG1024S can save power consumption and 80% of the packaging material can be recycled, making it an eco-friendly solution for your business network.

TP-LINK Green Technology

This new generation TL-SG1024S Gigabit Switch features the latest innovative energy-efficient technologies that can greatly expand your network capacity with much less power. It automatically adjusts power consumption according to the link status to limit the carbon footprint of your network. It also complies with the EU’S RoHS, prohibiting the use of certain hazardous materials. Besides, 80% of the packaging material can be recycled.

High Performance

All 24 ports are Gigabit RJ-45 ports which can provide large file transferring and also be compatible with 10Mbps and 100Mbps Ethernet devices. Featuring non-blocking switching architecture, TL-SG1024S forwards and filters packets at full wire-speed for maximum throughput. With 10KB Jumbo frame, the performance of large files transfers is improved significantly. And IEEE 802.3x flow control for Full Duplex mode and backpressure for Half Duplex mode alleviate the tra­ffic congestion and make The TL-SG1024S work reliably. It’s a perfect choice to update your network to Gigabit while protecting your previous investment properly.

Easy to Use

The auto features of this gigabit switch make installation plug and play and hassle-free. No configuring is required. Auto MDI/MDIX eliminates the need for crossover cables. Auto-negotiation on each port senses the link speed of a network device (10, 100, or 1000 Mbps) and intelligently adjusts for compatibility and optimal performance.

More from the Manufacturer

Ethernet Switch

24

No

No

Yes

24 x Gigabit Ethernet Network

Twisted Pair

Gigabit Ethernet

10/100/1000Base-T

2

• IEEE 802.3i
• IEEE 802.3u
• IEEE 802.3ab
• IEEE 802.3x

No

• 50 Hz
• 60 Hz

Power Supply

13.60 W

• Desktop
• Rack-mountable

1.7″

11.6″

7.1″

• 24-Port Gigabit Desktop/Rackmount Switch
• Power Cord
• Installation Guide
• Rackmount Kit
• Rubber Feet

China

Yes

Restriction of Hazardous Substances (RoHS)

3 Year
